Technical specifications:
- Main frame includes four light weight alloy main clamps of 160mm diameter
- Welding range 63mm to 160mm OD
- Layer clamps: 160x140, 140x125, 125x110, 110x90, 90x75, 75x63 (mm)
- Optional 2 piece liners: 160x140, 160x125, 160x110, 160x90, 160x75, 160x63 (mm)
- German hydraulic seals
- Removable PTFE coated heating plate with high accurate temperature control system
- Removable cast Aluminum electrically operated facing tool with current overload protection
- Electro-hydraulic pump with controls, and quick release hose
- Separate two-channel timer records time in soaking and cooling phases
- Working voltage: single phase ~220V ±10%, 50Hz (total power: 2.75kw, including trimmer: 1.0kw, heater: 1.0kw, hydraulic unit motor: 0.75kw) ~240V ±10%, 50Hz (total power: 2.94kw, including trimmer: 1.0kw, heater: 1.19kw, hydraulic unit motor: 0.75kw) Optional 60Hz also available
- Environment temperature: －10°～45°
- Whole machine consists of basic frame, heater, trimmer, hydraulic unit and support (for heater & trimmer)
- Optional stub end device for welding end fittings
- Optional wheeled trolley available
